9 Parameter reference
9.2 Parameter list | C00620
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00620
Parameter | Name:
C00620 | 16-bit system connection
Data type: UNSIGNED_16
Index: 23955
d
= 5D93
h
Connection parameters: 16-bit inputs
• Selection of the 16-bit output signals for connection with the 16-bit input signals.
• The selection list contains all 16-bit output signals which can be assigned to the 16-bit inputs mapped by the
subcodes.
Selection list
See
selection list - analog signals
Subcodes Lenze setting Info
C00620/1 0: Not connected Reserved
C00620/2 0: Not connected Reserved
C00620/3 0: Not connected Reserved
C00620/4 0: Not connected Reserved
C00620/5 0: Not connected LS_DisFree :wDis1
C00620/6 0: Not connected LS_DisFree :wDis2
C00620/7 0: Not connected LS_DisFree :wDis3
C00620/8 0: Not connected LS_DisFree :wDis4
C00620/9 0: Not connected LS_DisFree_a :nDis1_a
C00620/10 0: Not connected LS_DisFree_a :nDis2_a
C00620/11 0: Not connected LS_DisFree_a :nDis3_a
C00620/12 0: Not connected LS_DisFree_a :nDis4_a
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
