9 Parameter reference
9.2 Parameter list | C00833
216
Lenze · 8400 BaseLine D · Reference manual · DMS 5.5 EN · 01/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00833
C00909
Parameter | Name:
C00833 | 8-bit input
Data type: UNSIGNED_8
Index: 23742
d
= 5CBE
h
As of version 03.00.00
Display of the signal status of the binary inputs of different blocks
Selection list
0 False
1 True
Subcodes Info
C00833/1 L_NSet_1 : bRfg0
C00833/2 L_NSet_1 : bNSetInv
C00833/3 L_NSet_1 : bJog1
C00833/4 L_NSet_1 : bJog2
C00833/5 LS_SetError_1 : bSetError1
C00833/6 LS_SetError_1 : bSetError2
C00833/7 L_MPot_1 : bUp
C00833/8 L_MPot_1 : bInAct
C00833/9 L_MPot_1 : bDown
C00833/10 L_MPot_1 : bEnable
C00833/11 Reserved
C00833/12 L_PCTRL_1 : bIOff
C00833/13 L_PCTRL_1 : bEnableInfluenceRamp
C00833/14 LS_DCTRL : bCINH
C00833/15 LS_DCTRL : bFailReset
C00833/16 LS_DCTRL : bStatus_B0
C00833/17 LS_DCTRL : bStatus_B2
C00833/18 LS_DCTRL : bStatus_B3
C00833/19 LS_DCTRL : bStatus_B4
C00833/20 LS_DCTRL : bStatus_B5
C00833/21 LS_DCTRL : bStatus_B14
C00833/22 LS_DCTRL : bStatus_B15
C00833/23 L_RLQ_1 : bCw
C00833/24 L_RLQ_1 : bCcw
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00909 | Speed limitation
Data type: INTEGER_16
Index: 23666
d
= 5C72
h
Maximum positive/negative speed for all operating modes
Setting range
(min. value | unit | max. value)
0.0 % 175.0
Subcodes Lenze setting Info
C00909/1 120.0 % Max. pos. speed
C00909/2 120.0 % Max. neg. speed
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
