10 Function library
10.1 L_MPot_1
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Outputs
Parameter
Identifier
Data type
Value/meaning
nOut_a
INT
Output signal
Parameter Possible settings Info
C800 -199.9 % 199.9 Upper limit
• Lenze setting: 100.0 %
C801 -199.9 % 199.9 Lower limit
• Lenze setting: -100.0 %
C802 0.1 s 999.9 Acceleration time
• Lenze setting: 10.0 s
C803 0.1 s 999.9 Deceleration time
• Lenze setting: 10.0 s
C804 Inactive function
• Selection of response when deac-
tivating the motor potentiometer
via the input bInAct.
0 Keep value
(Lenze setting)
No further action; nOut_a retains its
value.
1 Deceleration to 0 The motor potentiometer returns to
0 % within the deceleration time T
if
.
2 Deceleration to lower limit The motor potentiometer runs
within the deceleration time T
if
to
the lower limit value ( C801 ).
3 Without ramp to 0 Important for the emergency stop
function
The motor potentiometer output im-
mediately changes to 0 %
4 Without ramp to lower limit The motor potentiometer output im-
mediately changes to the lower limit
value ( C801 ).
5 Acceleration to upper limit The motor potentiometer runs with
the acceleration time T
ir
to the upper
limit value ( C800 ).
C805 Init function
• Selection of response when swit-
ching on the device.
0 Load last value
(Lenze setting)
The output value being output du-
ring mains power-off is saved non-
volatilely in the internal memory of
the controller. It will be reloaded du-
ring mains power-on.
1 Load lower limit The lower limit value ( C801 ) is loaded
during mains power-on.
2 Load 0 An output value = 0 % is loaded du-
ring mains power-on.
