Lenze · 8400 BaseLine D · Reference manual · DMS 5.5 EN · 01/2014 · TD05
207
9 Parameter reference
9.2 Parameter list | C00574
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00574
C00581
C00598
Parameter | Name:
C00574 | Resp. to brake resist. overtemp.
Data type: UNSIGNED_8
Index: 24001
d
= 5DC1
h
Response when the permanently set threshold for monitoring the brake resistor utilisation has been reached.
Selection list
(Lenze setting printed in bold)
0 No Reaction
1 Fault
4 WarningLocked
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00581 | Resp. to LS_SetError_x
Data type: UNSIGNED_8
Index: 23994
d
= 5DBA
h
Selection of the error responses for application error messages
• An application error message is tripped by a FALSE-TRUE edge at the binary inputs bSetError1...2.
Selection list
0 No Reaction
1 Fault
2 Trouble
4 WarningLocked
Subcodes Lenze setting Info
C00581/1 1: Fault LS_SetError_1 : Resp. bSetError1
C00581/2 1: Fault LS_SetError_1 : Resp. bSetError2
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00598 | Resp. to open circuit AINx
Data type: UNSIGNED_8
Index: 23977
d
= 5DA9
h
Configuration of monitoring the analog input
 Analog terminals
Selection list
0 No Reaction
1 Fault
2 Trouble
4 WarningLocked
Subcodes Lenze setting Info
C00598/1 1: Fault Response to open circuit at AIN1 when being configured
as 4 ... 20 mA-current loop
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
