9 Parameter reference
9.2 Parameter list | C00007
174
Lenze · 8400 BaseLine D · Reference manual · DMS 5.5 EN · 01/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00007
C00010
Parameter | Name:
C00007 | Control mode
Data type: UNSIGNED_16
Index: 24568
d
= 5FF8
h
Selection of how the application is to be controlled.
Selection list
(Lenze setting printed in bold) Info
0 Wiring has changed This display appears when the preset configuration has
been reparameterised via the connection parameters.
10 Terminals 0 The technology application is controlled via the digital
input terminals of the controller:
• DI1 = fixed setpoint 1/3
• DI2 = fixed setpoint 2/3
• DI3 = activate DC injection braking
• DI4 = change of direction of rotation
12 Terminals 2 The technology application is controlled via the digital
input terminals of the controller:
• DI1 = fixed setpoint 1/3
• DI2 = fixed setpoint 2/3
• DI3 = quick stop
• DI4 = change of direction of rotation
14 Terminals 11 The technology application is controlled via the digital
input terminals of the controller:
• DI1 = change of direction of rotation
• DI2 = activate DC injection braking
• DI3 = motor potentiometer: Higher speed
• DI4 = motor potentiometer: Lower speed
16 Terminals 16 The technology application is controlled via the digital
input terminals of the controller:
• DI1 = fixed setpoint 1/3
• DI2 = fixed setpoint 2/3
• DI3 = CW rotation/quick stop
• DI4 = CCW rotation/quick stop
20 Keypad The technology application is controlled via the keypad:

C00002 : Device commands
 C00003 : Status of last device command
 C00727 : Executing control commands
 C00728 : Selecting analog setpoints
 Increase speed
 Reduce speed
21 PC The technology application is controlled via the "Free pa-
rameters" of the controller (PC control).
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00010 | Minimum analog setpoint
Data type: INTEGER_16
Index: 24565
d
= 5FF5
h
As of version 03.00.00
Lower limit for analog input
 Analog terminals
Setting range (min. value | unit | max. value)
0.0 % 100.0
Subcodes Lenze setting Info
C00010/1 0.0 % Min. analog setpoint
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
