Assign Processor / IP

Systems configured with LightDesigner to have only a single processor will automatically

resolve to and use the processor identity including IP settings created in the configuration

file.

For systems configured in LightDesigner to have multiple processors, you must manually

set the identity on each Paradigm ACP. Manually setting identity can be done from the

“Select New Settings” or “Edit Local Settings” menu list. These actions also select

processor IP settings.

When the Paradigm ACP does not have a LightDesigner configuration loaded, the “Select

New Settings” and “Edit Local Settings” menu lists will suggest settings based on the same

default addressing that is used in LightDesigner.

Once the Paradigm ACP has a valid LightDesigner configuration, the “Select New Settings”

and “Edit Local Settings” menu lists will suggest settings based on the loaded configuration

data.

Select New Settings

“Select New Settings” menu provides default processor name with associated default IP

settings for selection. ETC recommends that you use the default settings unless you have

specific needs such as a routed IP network or the use of DHCP IP services.

When the processor number has been previously specified from the front panel of the

Paradigm processor, that information is retained by the Paradigm ACP with the exception

of a “restore defaults” action. A restore defaults action from the processor face panel

changes defaults to match defaults used in LightDesigner (manual/10.101.10.101, etc) and

resets the identity to the unassigned processor state.

Edit Local Settings

N o t e :

If a configuration is running, changes from Edit Local Settings will overwrite

configuration data and persist the overwrite until a new configuration is loaded.
When the processor number has been previously specified from the front panel of

the Paradigm ACP, that information is retained by the ACP with the exception of

a “Restore Defaults” action.

Processor/IP Settings

Select New Settings

Edit Local Settings

Name: Unassigned
IP: [Automatic]
Mask:
GW:

All Paradigm processors must know who they are (Name) and

what their communication settings (IP) are before they can

communicate properly over Ethernet. These two settings are

referred to as “Identity”. When “Identity” is not known, the

processor name is displayed as “Unassigned Processor”.

Select new Settings

*Processor 1
10.101.10.101

Processor 2

Online

10.101.10.102
Basement
10.101.10.103
Processor 4

Online

An asterisk next to a processor name indicates the settings that

are currently in effect. “Online” is shown next to the name if the

processor is currently online.

Edit Local Settings

Processor Number:

1

IP Addressing:

Manual

IP:

10.101.10.101

Mask:

255.255.0.0

GW:

10.101.1.1

Apply and Exit

Edit Local Settings provides a more advanced selection

of processor name (id) and IP settings. User’s may

specify either automatic or manual IP addressing with

the ability to manually edit IP address fields.
