Training Projects - The Camera
There is a camera (viewing angle) that allows you to zoom, pan and rotate the "stage". There are some
default functions connected to the FORMAT key of Cobalt, and some functions are accessible by
patching the camera as a Device to a channel.
Default functions
Camera does not have to be patched as a DMX device.
Function Key Feedback
Zoom [FORMAT] & Wheel The view is
zoomed in/out
from the camera.
Pan stage right Right Arrow & Wheel Stage is panned to
the right around
the camera
Pan stage left Left Arrow & Wheel Stage is panned to
the left around the
camera
Tilt stage up Up Arrow & Wheel Stage is tilted up
around the camera
Tilt stage down Down Arrow & Wheel Stage is tilted
down around the
camera
DMX functions
Camera is patched as a device to channel 22 in the project A Demo Play. When the channel
controlling the camera is selected all functions are mapped to the device controls around the Main
Display.
FOCUS functions
• Pan = Pan stage
• Tilt = Tilt stage
• Pitch = Pitch the angle of the stage
Beam functions page 1
• Zoom = Zoom
• X <> = Move stage right/left along the X axis
• Y <> = Move stage up/down along the Y axis
• Z <> = Move stage in/out along the Z axis
Beam functions page 2
• Ambient L = Houselights
• Fixture L = Fixture lights
• Atmospher = Atmosphere/smoke
