Section II: Local and Telnet Management
88
Configuring STP Port Settings
To adjust STP port parameters, perform the following procedure:
1. From the Main Menu, type 3 to select Spanning Tree Menu.
2. From the Spanning Tree menu, type 7 to select Config STP port
settings.
The following prompt is displayed:
Starting Port to Configure [1 to 24] ->
3. Enter the number of the port you want to configure. To configure a
range of ports, enter the first port of the range.
The following prompt is displayed:
Ending Port to Configure [1 to 24] ->
4. To configure just one port, enter the same port number here as you
entered in the previous step. To configure a range of ports, enter the
last port of the range.
The STP Port Configuration window in Figure 23 is displayed.
Figure 23 Config STP Port Settings Window
5. Adjust the settings as desired. The parameters are described below.
1 - Participating
This parameter indicates whether the port is participating in the
spanning tree domain. This value cannot be changed.
Allied Telesyn AT-8024 Ethernet Switch
Config STP Port Settings
Configuring Ports 4 to 4
1 - Participating ...... Yes
2 - Path Cost .......... 10
3 - Port Priority ...... 128
4 - Port State ......... Forwarding
5 - Root Bridge ........ 00:A8:22:34:C1:2D
R - Return to Previous Menu
Enter your selection:
