Section II: Local and Telnet Management
120
Changing a PVID Value
The procedure in this section explains how to change a PVID value for a
port. As explained in Port-based VLAN Overview on page 93, a port
receives a PVID when it is assigned as an untagged port to a VLAN. A
port’s PVID will be the same as the VLAN’s VID to which it has been
assigned. For example, if you assign Port 4 on the switch as an untagged
port to a VLAN with a VID of 7, then the port will be assigned a PVID also
of 7.
The assignment of PVIDs is performed automatically by the AT-S39
software when you create a VLAN. There should be little need or reason
for you to manually change a PVID yourself. But the AT-S39 software
does allow you to adjust the value if you deem it necessary.
To change a PVID for a port, perform the following procedure:
1. From the Main Menu, type 2 to select VLAN Menu.
2. From the VLAN Menu, type 3 to select Port VLANS & Priorities.
The Port VLANS & Priorities window in Figure 33 is displayed.
Figure 33 Port VLANs and Priorities Window
3. Type 1 to select Port Number.
The following prompt is displayed:
Enter new value -> [1 to 26] ->
4. Enter the number of the port on the switch whose PVID you want to
change. Press Return.
Allied Telesyn AT-8024 Ethernet Switch
Port VLANs & Priorities
1 - Port Number
R - Return to Previous Menu
Enter your selection:
