Appendix A: Technical Specifications
174
AT-MCF2012LC, AT-MCF2012LC/1 and AT-MCF2032SP Media
Converter Modules
Specifications
Dimensions: 3.2 x 20.6 x 16.5 cm
(1.26 x 8.1 x 6.5 in.)
(H x W x D)
Weight - AT-MCF2012LC
and AT-MCF2012LC/1:
685 g (1.50 lb.)
Weight - AT-MCF2032SP: 0.78 kg (1.71 lb.)
Input Voltage: 12 volts and 3.3 volts
Maximum Input Current: 3 amperes
Maximum Power
Consumption:
36 watts
MTBF - AT-MCF2012LC
and AT-MCF2012LC/1:
300,000 hrs.
MTBF - AT-MCF2032SP: 220,000 hrs.
Twisted Pair Port
Pinouts
Table 32 lists the pins and their signals when the twisted pair ports are
operating in MDI or MDI-X configuration at 10 or 100 Mbps.
Table 29. 10/100Base-TX Port Pinouts
Pin MDI Signal MDI-X Signal
1 TX+ RX+
2 TX- RX-
3 RX+ TX+
6 RX- TX-
