Chapter 24: Replacing the Modules
160 Section II: Installation
5. To install a new module, refer to Chapter 12, “Installing a Media
Converter Module” on page 107.
Note
If the chassis is unmanaged, the channels in the replacement
module use their current settings or if the module is new, the default
values.
However, if the chassis has a management module or is part of a
stack, the settings on the replacement module are configured by the
management module to match the previous module. For further
information, refer to the AT-S85 and AT-S97 Management Software
Command Line User’s Guide
6. If you are not installing a new module, position the AT-MCF2KPNL1
Slot Cover and secure it by tightening the two captive screws.
Figure 89. Installing the AT-MCF2KPNL1 Slot Cover over a Media
Converter Slot
1
AT-M CF 2000
A T -MCF2012LC
AT-MC
F2KP NL1
1
AT-MCF2000
A T -MCF2012LC
AT-MCF2KPN
L1
