62 HP VMA SAN Gateway User’s Guide AM456-9026A
Analyzing Data for a Target
You can analyze target data in real-time or as historical trends, and choose from a variety of display
formats.
To analyze data for a selected target port, do the following:
1. Select Monitor > Monitor Targets. The Target Port Monitoring page appears.
2. Choose a target port, as described in Selecting a Target Port on page 61.
3. Select one of the following time intervals for data analysis:
— Real Time Displays data as it happens, in real time
— 1 H Displays aggregated data for the last hour
— 24 H Displays aggregated data for the last 24 hours
4. Choose the graph type from the drop-down list on the right.
• Line
• Area
• Stacked Line
• Stacked Area
The following example shows port data using a Stacked Area graph.
Administration
The Administration page of the HP VMA Web Interface provides a single point of contact where
you can perform a wide range of SAN Gateway administration tasks.
You must have Admin privileges to perform the following tasks using the Administration function
pages.
