32
HP VMA SAN Gateway User’s Guide
AM456-9026A
•
Live Stats—Shows real-time values for bandwidth, IOPS and latency on a LUN level or
container level. Click the settings icon in the upper right corner to customize the display.
•
Indicators—Shows the LED, temperature and fan status for a container on an array. Click the
settings icon in the upper right corner to customize the display.
•
Flash/VIMM Status—Shows the VIMM status (number active, down, etc.) and the remaining
length of flash life for a container on an array. Click the settings icon in the upper right corner
to customize the display.
•
Container Status—Shows the amount of space used and available on the container, the number
of LUNs, and provides an HA status indicator for a container on an array. Click the settings
icon in the upper right corner to customize the display.
•
Port Stats—Shows the Received and Sent statistics for Fibre Channel ports in real-time, per
hour, or per day values for a port within a container. Click the settings icon in the upper right
corner to customize the display.
Note:
For instructions on how to change the information shown on a gadget, see
Customizing the Dashboard
You can customize the dashboard by adding, removing, and rearranging the placement of the
gadgets for optimum efficiency.
To customize the dashboard and view data, do the following:
1.
Log in to the SAN Gateway, as described in
Logging In and Out of the Web Interface
26. The default dashboard appears.
2.
Click the plus icon (+) in the lower right corner allows to access the toolbar.
Note:
If you are not able to view the dashboard, you may need to upgrade your browser. For
more information, see
