AM456-9026A HP VMA SAN Gateway User’s Guide 37
5. Check the VIMM, Controller, and ambient temperatures. Green is healthy, yellow a caution,
and red a warning.
6. View a high-level synopsis of the flash VIMM statistics in the far left panel.
Viewing VIMM Status
The HP VMA Cluster Status page can be expanded to view board-level information about a
connected VMA Memory Array. The Board Status page shows a color-coded array of VIMMs with
indicator boxes for alarm status, temperature, and remaining lifetime.You can move your cursor
over a VIMM to view a detailed status.
To view VIMM statistics, do the following:
1. Select Home > Cluster, to display the HP VMA Cluster Status page.
2. Click the Show Board Status tab.
3. For general status information about specific VIMMs, move the cursor over the VIMM
number.
4. To view Alarm, Temp, or Lifetime information, move the cursor over the appropriate indicator
box.
Viewing VIMMs by RAID Group or Category
You can selectively display RAID group information on the Board Status page, as well as category
details.
To view RAID group and category board-level information, do the following:
1. Select Home > Cluster, to display the HP VMA Cluster Status page.
2. Click the Show Board Status tab.
3. To view VIMMs by RAID group, select a RAID Group number at the top-center of the Board
Status panel.
