DUAL MEASUREMENT

51

ACV

Hz

Measure the frequency response of
devices such as amplifiers or
buffers*.

* The frequencies of the amplifier
output must be within the DMM’s
measurable AC bandwidth for the
amplitude at a spot frequency to be
measured accurately.

Frequency Response

INPUT

V

W

COM

V

V

o

f

AMP

V

o

V

in

V

in

f

The following table shows the available measurement
combinations.

1st Display

[2]

2nd Display

[2]

ACV

DCV

ACI

DCI

Hz/P

2W/4W

[1]

ACV

DCV

ACI

DCI

Hz/P

2W/4W

[1]

Note

[1] 2W/4W measurements in combination with other

measurements are possible but may not be practical as
the measurement accuracy is not guaranteed.

[2] When two different measurements are taken, there is a

switching delay between the first measurement and the

second measurement.

1st Measurement
item setting

Choose a basic measurement from
the above table. Example: press the

ACI key.

Page 23

Example:

ACI
