GDM-8261A User Manual

4

View Serial Number ........................................... 75

Trigger Setting ................................................... 76

Filter Setting ..................................................... 79

Display Setting .................................................. 83

Measurement Configuration Settings ............... 84

ADC Setting ....................................................... 88

Frequency / Period Settings .............................. 93

Identification Settings ....................................... 96

S

TORE/

R

ECALL ............................................................... 97

Store Measurement Record ............................... 98

Recall Measurement Record .............................. 99

Save Instrument Settings ................................ 100

Recall Instrument Settings .............................. 101

S

CANNER (OPTIONAL) ................................................. 103

GDM-SC1 Scanner Specifications ................... 104

Scanner Installation ........................................ 104

Setup Scan ...................................................... 113

Run Scan ......................................................... 120

D

IGITAL I/O ................................................................... 123

Digital I/O Terminal Configuration ................. 124

R

EMOTE CONTROL ....................................................... 130

Configure Interface .......................................... 132

Web Control Interface ..................................... 159

Command Syntax ............................................ 163

Command Set .................................................. 164

F

AQ ................................................................................ 209

A

PPENDIX ...................................................................... 211

Firmware Version ............................................ 212

Fuse Replacement ........................................... 213

Menu Tree ....................................................... 215

Specifications .................................................. 217

EC Declaration of Conformity .......................... 227
