APPENDIX
219
DC Characteristics [3]
DC Voltage [1]
Range [4]
24 Hour
23˚C±1˚C 90 Day
23˚C±5˚C 1 Year
23˚C±5˚C Temperature
Coefficient/˚C
[6]
100.0000 mV 0.0030 + 0.0030 0.0040 + 0.0035 0.0050 + 0.0035 0.0005 + 0.0005
1.000000 V 0.0015 + 0.0004 0.0020 + 0.0005 0.0035 + 0.0005 0.0005 + 0.0001
10.00000 V 0.0020 + 0.0006 0.0030 + 0.0007 0.0048 + 0.0007 0.0005 + 0.0001
100.0000 V 0.0020 + 0.0006 0.0035 + 0.0006 0.0081 + 0.0006 0.0005 + 0.0001
1000.000 V 0.0025 + 0.0006 0.0044 + 0.0010 0.0090 + 0.0010 0.0005 + 0.0001
Accuracy Specifications: ± ( % of reading + % of range )
Resistance [1] [4] [5]
Range [4]
Test
Current 24 Hour
23˚C±1˚C 90 Day
23˚C±5˚C 1 Year
23˚C±5˚C Temperature
Coefficient/˚C
[6]
100.0000 Ω 1 mA 0.0030 + 0.0030 0.008 + 0.004 0.010 + 0.004 0.0008 + 0.0005
1.000000 kΩ 1 mA 0.0020 + 0.0005 0.008 + 0.001 0.010 + 0.001 0.0008 + 0.0001
10.00000 kΩ 100μA 0.0020 + 0.0005 0.008 + 0.001 0.010 + 0.001 0.0008 + 0.0001
100.0000 kΩ 10μA
0.0020 + 0.0005 0.008 + 0.001 0.010 + 0.001 0.0008 + 0.0001
1.000000 MΩ 3.5μA 0.002 + 0.001 0.008 + 0.001 0.010 + 0.001 0.0010 + 0.0002
10.00000 MΩ 350nA 0.015 + 0.001 0.020 + 0.001 0.040 + 0.001 0.0030 + 0.0004
100.0000 MΩ 350 nA//
10 MΩ
0.300 + 0.010 0.800 + 0.010 0.800 + 0.010 0.1500 + 0.0002
Accuracy Specifications: ± ( % of reading + % of range )
DC Current [1]
Range [4]
Burden
Voltage 24 Hour
23˚C±1˚C 90 Day
23˚C±5˚C 1 Year
23˚C±5˚C Temperature
Coefficient/˚C
[6]
100.0000 μA < 0.015 V 0.01 + 0.02 0.04 + 0.025 0.05 + 0.025 0.002 + 0.0030
1.000000 mA < 0.15 V 0.007 + 0.005 0.030 + 0.005 0.05 + 0.005 0.002 + 0.0005
10.00000 mA < 0.07 V 0.005 + 0.010 0.030 + 0.020 0.05 + 0.020 0.002 + 0.0020
100.0000m A < 0.7 V 0.01 + 0.004 0.030 + 0.005 0.05 + 0.005 0.002 + 0.0005
1.000000 A < 0.8 V 0.05 + 0.006 0.080 + 0.010 0.100 + 0.010 0.005 + 0.0010
10.00000 A < 0.5 V 0.10 + 0.008 0.120 + 0.008 0.15 + 0.008 0.005 + 0.0008
Accuracy Specifications: ± ( % of reading + % of range )
Continuity [2] [7]
Range [4]
Test Current
24 Hour
23˚C±1˚C 90 Day
23˚C±5˚C 1 Year
23˚C±5˚C Temperature
Coefficient/˚C
[6]
1000.000Ω 1 mA 0.002 + 0.030 0.008 + 0.030 0.010 + 0.030 0.001 + 0.002
Accuracy Specifications: ± ( % of reading + % of range )
Diode Test [2] [7]
Range [4]
Test Current
24 Hour
23˚C±1˚C 90 Day
23˚C±5˚C 1 Year
23˚C±5˚C Temperature
Coefficient/˚C
[6]
1.000000 V 1 mA 0.002 + 0.010 0.008 + 0.020 0.010 + 0.020 0.001 + 0.002
Accuracy Specifications: ± ( % of reading + % of range )
