GDM-8261A User Manual
114
1 Count# 3 2 4 5 6 7 8 9 10 11 12 Delay Delay
Timer Timer
Scan
CH
101
CH
102
CH
103
CH
104
CH
101
CH
102
CH
103
CH
104
CH
101
CH
102
CH
103
CH
104
Timer
Delay
Trigger delay time
Example: Scan channels 1~4 with a count setting of 12.
Step Measures a single channel in the specified
range (Channel MIN~MAX)at each
trigger event. Timer settings (page 115)
apply for each channel.

1 Count#
CH
101
Delay
Timer
2
CH
102
Delay
Timer
3 Delay
Timer
4
CH
104
Delay
Timer
5
CH
101
Delay
Timer
6
CH
102
Step
CH
103
12
Timer Timer
Delay
Example: Step through channel 1~4 with a count of 12.
Monitor Selects just one channel and continuously
measures it.
Setup Simple Scan
Ensure the scanner has been installed before trying to
configure the scanner (page 104).
Panel operation 1. Press the Shift key, the 2nd key
(MENU), the Left key. The Scan
menu appears.
/ EXIT SHIFT
2ND
MENU
HOLD
2. Press the Down key. The Simple
Scan menu appears.
