Fuse Replacement
Replace AC Source Fuse
Steps 1. Take off the power
cord and remove the
fuse socket using a
minus driver.
1
0
0
2 2 0
1 20
240
2. Replace the fuse in the
holder.
220
100
1
2
0
2
4
0
3. Ensure the correct line
voltage is lined up with
the arrow on the fuse
holder. Insert the fuse
socket.
220
100
1
2
0
2
4
0
220
100
1
2
0
2
4
0
1
0
0
2
2
0
1 20
240
Rating 0.315AT, 100/120VAC; 0.125AT, 220/240VAC
