Digital i/o, Igital i/o – GW Instek GDM-8261A User manual User Manual
Page 123
DIGITAL I/O
123
D
IGITAL I/O
The rear panel Digital I/O terminal outputs the result of
Compare measurements to external devices.
HOLD
COMP
Terminal
configuration
Digital I/O Terminal Configuration ...................... 124
Application
Application: Compare measurement .................... 125
Application: External trigger ................................. 128
