PSU Series User Manual
184
Auto Calibration Parallel
Control F-16
0 = Disable
Measurement Average
Setting F-17
0 = Low
Alarm Recovery and
Output Status F-18
0 = Safe Mode
Lock Mode F-19 0:Lock Panel, Allow Output OFF
Setup Rear USB Speed F-22 2 = Auto Detect Speed
GPIB address F-23 8
GPIB Enable/Disable F-24 1 = Enable GPIB
SCPI Emulation F-26 0 = GW Instek
LAN setting
LAN Enable
F-36 1 = ON
DHCP F-37 1 = ON
Power On Configuration
Socket Server
Enable/Disable
F-57 1 = Enable
Web Server
Enable/Disable
F-59 1 = Enable
Web Password
Enable/Disable
F-60 1 = Enable
UART Mode F-70 1 = RS232
UART Baudrate F-71 7 = 115200
UART Data Bits F-72 1 = 8 bits
UART Parity F-73 0 = None
UART Stop Bit F-74 0 = 1 bit
UART TCP F-75 0 = SCPI
UART Address (For TDK) F-76 31
CV Control F-90 0 = Control by local
CC Control F-91 0 = Control by local
Output Status when
Power ON
F-92 0 = Safe Mode (Always OFF)
Master/Slave
Configuration
F-93 0 = Independent
External Output Logic F-94 0 = High ON
Monitor Voltage Select F-96 0 = 5V
Control Range F-97 0 = 5V[5kΩ]
External Output Control
Function
F-98 0 = OFF
