Chapter 3: Quickstart Project Pointe Controller User Guide
38
3.3 Associating Tags with I/O Points
At this point, we have tag-names defined. However, we haven’t configured our
I/O and haven’t associated our tag-names with particular I/O points. Let’s do that
now:
1. From the Project menu, choose Configure I/O. The I/O Configuration
window will appear.
2. Next to Slot 1 module type, click the drop-down menu and select
OL2201. This configures the OL2201 module in slot 1 of the Pointe
Controller base unit.
