Pointe Controller User Guide Appendix B: Flow Chart Command Reference
309
B.3.4 String Mid
This command can be selected from the String commands list.
When used in a Flow Chart, the String Mid command extracts a sub-string, of a
specified length and starting from a specified position, from a given string.
Parameters for this command include:
Destination String – The String tag to which the extracted sub-string
will be written.
To configure the Destination String parameter, click the button to
open a standard Select String Tag dialog.
NOTE: If the defined length of the Destination String is not long enough
to receive the result of the command, then the output will be truncated.
No error will be generated.
Source String – The string from which the sub-string will be extracted.
The value of Source String may be a String tag, a literal string enclosed in
single quotes (‘ ’), or some other logical expression that is evaluated every
time the block is executed.
To configure the Source String parameter, click the button to open a
standard Build String Argument dialog.
NOTE: Source String is not modified by the execution of this command.
Number Chars – The length of the sub-string, in characters, to be
extracted.
The value of Number Chars may be an Input/Memory/Output tag, a literal
numeric value, or some other logical expression that is evaluated every
time the block is executed.
To configure the Number Chars parameter, click the button to open a
standard Build Argument dialog.
