1.4 Available Parts and Accessories
The Pointe Controller system is designed to be extremely modular and flexible. As
such, all Pointe Controller parts and accessories are sold separately. For
availability and pricing, please call Nematron at 1-800-636-2876, or visit us on the
Web at http://www.nematron.com/Sales and find a certified Nematron distributor
near you.
A complete list of available parts and accessories follows:
PART # DESCRIPTION
PTC-5800 Pointe Controller base unit, 8-slot
NOTE: First-time users must also order at least one PointeControl
software CD (part # NS-PTC) and one RS-232 download cable (part # OL-
CBL-DNL). For more information, see below.
Software
NS-PTC PointeControl Development Framework and Runtime Monitor (software
CD), for Pointe Controller program development and debugging. Single-
seat license that can be used to program multiple Pointe Controller
units. Runs on Microsoft Windows NT 4.0, Windows 2000, and Windows
XP.
Accesories
OL-CBL-DNL Pointe Controller Boot Program download cable — connect’s PC’s RS-232
port to Pointe Controller’s RS-232 port for IP address setting.
OL-CBL-X01 Ethernet CAT5 crossover cable, 6 foot, red — for direct connecting PC to
Pointe Controller for program downloading.
OL-CBL-P01 Ethernet CAT5 patch cable, 6 foot, black — for connecting Pointe
Controller to an Ethernet network.
CBL-PV10 Pointe Controller to Nematron PowerView™ Touchscreen HMI
communication cable — supports Modbus protocol on Serial.
OL-PS1 Power Supply — 120 VAC to 24 VDC, 1 Amp output, wall pluggable.
OptiLogic I/O Modules
OL0001 Blank Module — recommended to fill unused slots in base unit.
OL2104 4-point Relay Output Module, 5-30VDC or 5-132VAC, 2A/point @ 24VDC,
1A/point @ 120VAC, isolated contact outputs.
OL2108 8-point Relay Output Module, 5-30VDC or 5-132VAC, 2A/point @ 24VDC,
1A/point @ 120VAC, 4A/common, 2 commons.
OL2109 8 points, 5-40VDC sinking output. 300 mA sinking capability / point.
OL2111 8 points, solid-state relay output. 15-132VAC, 0.5A/point.
OL2201 8-point digital input simulator.
OL2205 4-point AC/DC input. 10-30V (sourcing or sinking), isolated input and
return lines.
