Chapter 5: Developing Controller Programs Pointe Controller User Guide
172
TOOL DESCRIPTION FOUND ON...
Rising Edge Detector Page 345
Set-Dominant Bistable Page 346
Reset-Dominant Bistable Page 348
5.9.2 Timer and Counter Blocks
Clicking on this toolbar button activates the Timer and Counter Blocks
toolbar, which allows the placement of timing and counting functions
in your ladder diagram.
This library includes the following blocks:
TOOL DESCRIPTION FOUND ON...
Timer, Pulse Page 350
Timer, ON Delay Page 351
Timer, OFF Delay Page 352
Counter, Up Page 353
Counter, Down Page 355
Counter, Up/Down Page 356
5.9.3 Math Blocks
Clicking on this toolbar button activates the Math Blocks toolbar, which
allows the placement of mathematical functions in your ladder
diagram. Activation of the Math Blocks toolbar terminates any active
block insertion mode, forcing a selection from the Math Blocks library
before insertion mode is restored.
This library includes the following blocks:
TOOL DESCRIPTION FOUND ON...
Add Page 359
Subtract Page 360
