SierraFC M164 Protocol Analyzer User Manual 41
Easy Mode (Pre‐Defined Setups) Teledyne LeCroy
Projects
You can define a new project, starting with the default project definition, or modify the
settings for the last project run.
New Default Project
To start a New project, select File on the main menu bar and choose Protocol Analyzer to
open a new project with default settings that you can modify (see
“Main Window” on
page 33 ).
Last Project
Clicking the Green button opens the last project run, so you can modify it.
Project File Types
Projects have the following file types:
 *.cfg Display Configuration file (in the System folder “Config” subfolder)
 *.fcc Protocol Analyzer/Capture Project/Viewer file
 *.fcs Sample file
 *.wsf Workspace file
Example Projects
The Analyzer includes example projects that you can use to perform an immediate
analysis without any setup.
The Analyzer system software has a pre‐defined folder (directory) structure for storing all
files. All example files are in the Examples folder under the SierraFC M164 folder.
It is strongly recommended that you open some example files to see types of projects
that you can create.
