Set Time Stamp Origin
Right‐click in the sample viewer to open the fly out menu:
Figure 3.63: Bookmark Found Example in Data Viewer Display
Highlight Set Time Stamp Origin and choose either Absolute, Trigger, Current Position, or
Based on system time.
Quick Search
The Quick Search menu and button options permit you to examine any data capture file
to quickly locate the packet or data pattern.
Note:
Only items captured in the sample file are enabled for search.
To perform an initial search, select Edit > Search or click the Search button. The
Quick Search dialog displays (see Figure 3.64 on page 240 ). Select a packet from the
dropdown menu, select Show or Hide to Show/Hide items and select AND/OR as shown
below.
