SierraFC M164 Protocol Analyzer User Manual 285
Settings in Advanced Mode Teledyne LeCroy
Extended Link Service‐ Reply Refer to section “Extended Link Service ‐ Reply” on
page 59 .
GS
Generic Link Service‐
Request
Refer to section “Generic Link Service ‐ Request” on
page 60 .
Generic Link Service‐
Request, Reply Refer to section “Generic Link Service ‐ Request, Reply” on
page 61 .
Generic Link Service‐ Reply Refer to section “Generic Link Service ‐ Reply” on page 62 .
SW
Switch Internal Link ‐
Request
Refer to section “Switch Internal Link Service ‐ Request” on
page 63 .
Switch Internal Link ‐
Request, Reply Refer to section “Switch Internal Link Service ‐ Request,
Reply” on page 64 .
Switch Internal Link ‐ Reply Refer to section “Switch Internal Link Service ‐ Reply” on
page 65 .
FICON
FICON (Any Data
Information Block Type)
Refer to section “Any Data Information Block Type” on
page 66 .
FICON (Data) Refer to section Refer to section “Add FICON Data” on
page 67 .
FICON (Command) Refer to section Refer to section “Add FICON Command” on
page 68 .
FICON (Status) Refer to section Refer to section “Add FICON Status” on
page 70 .
FICON (Control) Refer to section Refer to section “Add FICON Control” on
page 73 .
FICON (Command‐Data) Refer to section “Add FICON Command‐Data” on page 75 .
FICON (Link‐Control) Refer to section “Add FICON Link‐Control” on page 77 .
FCAE 1553
FCAE ‐ ASM
Refer to section “FCAE‐ASM” on page 79.
FCAE 1553 (Any) Refer to section “FCAE‐1553 Any” on page 80 .
FCAE 1553 (Data) Refer to section “Add FCAE‐1553 Data” on page 81 .
FCAE 1553 (Command) Refer to section “Add FCAE‐1553 Command” on page 82 .
FCAE 1553 (Status) Refer to section “Add FCAE‐1553 Status” on page 85 .
FCAE RDMA
FCAE‐RDMA FCP SCSI
Command ‐ With Target
Notification
Refer to section “FCAE‐FCP SCSI Command ‐ RDMA With
Target Notification” on page 86 .
FCAE‐RDMA FCP Command
Frame Information Unit
With Target Notification Refer to section “FCAE RDMA FCP Command Frame
Information Unit With Target Notification” on page 87 .
Event Description
