Single Loop Process Controller Instruction Manual
82 Ratio PID Controller
Table 7-4. Contact Output (CCO) Module
Title Symbol
CCO0
Datapoint
Default
Contact Output
(Display Only) CCO L024 0
Contact Output
Invert OINV L288 0
Tag Name COTAG A280 CCO0
Table 7-5. Controller Module (CON-0)
Title Symbol
CON-0
Datapoint
Default
Control Alarm
Mode AIX B335 1
Control Action RSW L106 1
Reverse Valve RSV L109 0
Manual Fallback
Disable MFD L120 0
Alarm Limit 1 PL1 C103 100
Alarm Limit 2 PL2 C104 0
Alarm Dead Band ADB C105 2
Proportional Band PB C106 100
Reset Time TR C107 0
Rate Time TD C108 0
Manual Reset MR C111 50
Controller Span IR C115 100
Controller Lower
Range ILR C116 0
Control Tag Name CTAG A000 CON-0
Engineering Units CEU A001 Percent
