Single Loop Process Controller Instruction Manual
Single Loop (PID) Controller 59
← Output Decrease
(EMODE Cursor
Control) The output indicator decreases when
this pushbutton is pressed and held.
Release the pushbutton when the
desired output level is reached. This
pushbutton is for Manual operation
only. For configure or display functions,
the cursor shifts one position to the
left each time this pushbutton is
pressed. When pressed and held,
characters continue to shift left one
position at a time. Maximum
character length is 10 characters
(9 character shifts).
→ Output Increase
(EMODE Cursor
Control) The output indicator increases when
this pushbutton is pressed and held.
Release the pushbutton when the
desired output level is reached. This
pushbutton is for Manual operation
only. For configure or display functions,
the cursor shifts one position to the
right each time this pushbutton is
pressed. When pressed and held,
characters continue to shift right
one position at a time. Maximum
character length is 10 characters
(9 character shifts).
F1, F2 Page Forward
and
Page Back These two push buttons have similar
functions, but work in reverse of one
another. They are the bar graph -
parameter display toggles. The two
display types interchange and
alternately appear each time either
one of these two push buttons is
pressed. Pushbutton F2 is used to select the
configure or display functions in
EMODE. Pressing
F2 in EMODE
alternately selects one function or
the other.
F3 (EMODE
E NTER
Key)
ln the configuration function,
pressing this pushbutton causes
the addressed datapoint to be
altered with the character string
that was entered with the EMODE
Cursor Control and Character
Select pushbuttons. In the display
function, pressing this pushbutton
causes the addressed datapoint to
display its contents.
● Mode Select/Alarm
Reset This push button clears the flashing ALARM message, but the alarm
indication remains until the process variable is restored within tolerable
limits past dead band. It is also used to toggle between Operator and
Engineering modes. If no ALARM message is present, pressing this
pushbutton will toggle the instrument between operator mode and
engineering mode.
Table 5-1. Single Loop Controller Pushbutton Functions
Button Title Operator Mode Engineering Mode
