Single Loop Process Controller Instruction Manual
Single Loop (PID) Controller 63
Manual Reset MR C111 50
Controller Span IR C115 100
Controller Lower
Range ILR C116 0
Control Tag Name CTAG A000 CON-0
Engineering Units CEU A001 Percent
Table 5-7. Communication Module
Title Symbol Datapoint Default
Instrument
Address IA B01 0
Baud Rate BR B02 253
No Parity CP L256 0
No Byte
Stuffing CB L258 0
Datalink
Disable DLD L257 0
Table 5-8. System Module
Title Symbol
System Module
Datapoint
Default
Function Index FIX B00 0
Display
Brightness
Index BRIGHT B12 4
EASY-TUNE
Enable ETE B08 0
Unit Tag Name TAG A08 SL5100
Table 5-6. Controller Module (CON-0) (Continued)
Title Symbol
CON-0
Datapoint
Default
