Single Loop Process Controller Instruction Manual
36 Front Panel
3.4.1 Using the Hand-Held Configurer
The Hand-Held Configurer (HHC) is a portable terminal designed to interface with the instrument through
the configuration port that is located behind the pull-down door on the front panel of the instrument (see
Figure 3-1 ).
The HHC is available in two versions:
1. A Standard HHC with capabilities to display or alter specifically addressed parameters in the
instrument database. The part number to order this HHC is 69881821101.
2. An HHC with memory function capabilities to save the entire database of an instrument onto a
removable storage cartridge or load an instrument database from the HHC storage cartridge.
The part number to order this HHC is 6988182U02.
3.4.1.1 Hand-Held Configurer Set Up
The Hand-Held Configurer is shipped pre-configured to operate with the instrument. If the HHC does not
operate correctly, check the configuration by entering set up mode. To enter HHC set up mode, press
C
ONTROL ,
S HIFT , and
F1 simultaneously. The correct configuration is shown below.
If the configuration is not correct, it can be altered while in set up mode. When set up mode is entered, the
current baud rate setting is displayed on the top line; the following choices are also displayed:
If the baud rate setting is incorrect, it can be changed by pressing F1. Each time the F1 key is pressed, an
optional setting for the parameter is displayed on the top line. When the desired setting appears, press
F2
to select it and see the current setting for the next parameter (or press F3 to select it and see the current
setting for the previous parameter). If the setting is not correct, use F1 to cycle through available settings.
All parameters can be checked and changed in this way.
Press
F4 (Quit) to exit set up mode; any changes made will stay in effect until the HHC is disconnected.
Use
F5 to save changes to the instrument’s memory; the Hand-Held Configurer can then be disconnected
and the changes to the instrument will remain in effect.
Option Selection Option Selection Option Selection
Baud 9600 Display PE Enabled Handshake Disabled
Data Bits* 7 Repeat Fast Self Test Disabled
Parity** Space Echo Disabled
* Not applicable for U02 version.
**Parity = None for U02 version.
Key Selection
F1 Change Parameter
F2 Next
F3 Previous
F4 Quit
F5 Save
