Single Loop Process Controller Instruction Manual
42 Configuration Parameters
4.2 Factory Standard Configuration
The instrument is shipped from the factory configured as summarized in Table 4-2 .
If the state of the database is unknown, the instrument can be returned to the factory standard
configuration with two datapoint entries:
1. Set B00 to 98 to default the database.
2. Set B00 to 1 to start functioning as a Single Loop Controller.
If the unit is to be operated online, it must be installed as described in Section 2, Installation .
ANI0 (PV Input) and ANO0 (Output) must be connected, and the unit must have power applied.
Table 4-2. Factory Standard Configuration
Datapoint Value Attribute
B000 1 This value indicates Single Loop PID Controller operation.
C106 100 Proportional Band = 100%.
C107 0
No Reset (TR) action.
C108 0 No Derivative (TD) action.
B335 1 No Alarms.
C256 100 ANI0 Engineering Span Input (Process Variable [PV] Input) = 0% - 100%.
L416 0 ANI0 Input Voltage Range is 1 - 5 V.
L106 1 Reverse Switch is set so that the instrument output decreases as PV increases.
L115 0
Remote Setpoint Disabled indicates the setpoint value established in Local
mode remains in effect when the instrument is placed in Remote mode.
Displays
1. As configured: Display of Single Loop Controller, Analog Back-up Controller,
Ratio Controller, or Automatic Manual Station
2. Parameter 1 Display
