Single Loop Process Controller Instruction Manual
26 Front Panel
A/M Auto/Manual Select This pushbutton is the Auto/
Manual mode toggle. When
toggled to Auto, an A appears
before the R or L (for Remote or
Local), in the lower middle right
of the display. When toggled to
Manual, an M appears before the
R or L (for Remote or Local), in
the lower right of the display.
Auto indicates the process is
under instrument control. Manual
indicates the process is
controlled by the instrument
panel pushbuttons (e.g., output
increase and decrease.
← Output Decrease
(EMODE Cursor
Control) The output indicator decreases
when this pushbutton is pressed
and held. Release the
pushbutton when the desired
output level is reached. This
pushbutton is for Manual
operation only. For configure or display
functions, the cursor shifts one
position to the left each time
this button is pressed. When
pressed and held, characters
continue to shift left one
position at a time. Maximum
character length is 10
characters (9 character shifts).
→ Output Increase
(EMODE Cursor
Control) The output indicator increases
when this pushbutton is pressed
and held. Release the push
button when the desired output
level is reached. This push
button is for Manual operation
only. For configure or display
functions, the cursor shifts one
position to the right each time
this button is pressed. When
pressed and held, characters
continue to shift right one
position at a time. Maximum
character length is 10
characters (9 character shifts).
F1, F2 Page Forward and
Page Back These two push buttons have
similar functions, but work in
reverse of one another. They are
the bar graph - Param display
toggles. The two display types
interchange and alternately
appear each time either one of
these two pushbuttons is
pressed. Pushbutton F2 is used to
select the configure or display
functions in EMODE. Pressing
F2 in EMODE alternately
selects one function or the
other.
Table 3-1. Pushbutton Functions (Continued)
Push-
button
Title Operator Mode Engineering Mode
