Micromod Micro-DCI: 53SL5100A Single Loop Controller - Manual (Page 147)

Single Loop Process Controller Instruction Manual
Database 139
ANI1
Engineering
Zero ZERO C277 0 This is the lower range value of analog input 1.
ANI0
Calibrate
Span CIS C296 This is the calibration span adjustment. This parameter is
factory set and should not need adjustment under
normal operation. See
Section 12.3 for adjustment.
ANI1
Calibrate
Span
CIS C297
This is the calibration span adjustment. This parameter is
factory set and should not need adjustment under
normal operation. See
Section 12.3 for adjustment.
ANO0
Calibrate
Span
COS C300
This is the calibration span adjustment. This parameter is
factory set and should not need adjustment under
normal operation. See
Section 12.3 for adjustment.
Parameter
Point 1
Designator PDA F087 C106
value A database datapoint whose contents will be displayed
under the Point 1 Name (e.g., C103 to display the Alarm
Limit 1 setting) of the parameter display.
Parameter
Point 2
Designator PDB F088 C107
value A database datapoint whose contents will be displayed
under the Point 2 Name (e.g., C104 to display the Alarm
Limit 2 setting) of the parameter display.
Parameter
Point 3
Designator PDC F089 C108
value A database datapoint whose contents will be displayed
under the Point 3 Name (e.g., C105 to display the Alarm
Dead Band) of the parameter display.
ANI0 Input
(Display
Only) ANI H000 0 This is the value in engineering units of the measured
input for ANI0 after all signal conditioning has been
applied.
ANI1 Input
(Display
Only) ANI H001 0 This is the value in engineering units of the measured
input for ANI1 after all signal conditioning has been
applied.
CCI Input
(Display
Only) CCI L000 0 When open, a 4 - 24 V dc input signal = 0 when IINV = 0.
When open, a 4 - 24 V dc input signal = 1 when IINV = 1.
When closed, a < 1 V dc input signal = 1 when IINV = 0.
When closed, a < 1 V dc input signal = 0 when IINV = 1.
CCO Output
(Display
Only) CCO L024 0 If CCO = 0 and OINV = 0, then it is open.
If CCO = 0 and OINV = 1, then it is closed.
If CCO = 1 and OINV = 0, then it is closed.
If CCO = 1 and OINV = 1, then it is open.
Control
Action
RSW L106 1
When set to a 0, the controller output increases as the
process value increases.
When set to a 1, the controler output decreases as the
process value increases.
Table C-2. Database (Continued)
Title Symbol Datapoint Default Attribute
