Micromod Micro-DCI: 53SL5100A Single Loop Controller - Manual (Page 13)

Single Loop Process Controller Instruction Manual
Introduction 5
1.3 Specifications
Table 1-1. Specifications
Item Specification(s)
Power Requirements (as specified)
Power Consumption (AC/DC operation)
Internal Power Supply:
Available Power Output for Transmitters
Output Ripple
22 - 26 V dc
108-132 V rms
216 - 264 V rms
50/60 Hz
36 VA maximum
25 V dc ± 1 V dc @ 80 mA maximum, short
circuit protected.
200 mV p-p maximum
Analog Input (ANI0, ANI1) Signals (all analog
inputs are referenced to signal common)
Quantity
Signal Range
Input Impedance
Measurement Accuracy
2 (ANI0, ANI1)
0 - 5 V dc or 1 - 5 V dc (0 - 20 mA and 4 - 20
mA dc respectively).
Note: The rear terminal board has the
appropriate resistors for ANI0 and ANI1.
1 megohm minimum for voltage inputs; value of
ranging resistor for current signals.
±0.1% of span
Contact Input CCI0 Signal (is referenced to
power common)
Quantity
Type
Permitted Contact Resistance
Open/Close Contact Duration
Contact Recognition Level Closed
Contact Recognition Level Open
1 (CCI0)
discrete input
100 ohm maximum
for open recognition: 0.05 seconds minimum
for closed recognition: 0.05 seconds minimum
1 V dc maximum
4 V dc to 24 V dc
