Single Loop Process Controller Instruction Manual
4 Introduction
1.2 Model Number Breakdown
Refer to the MicroMod data sheet or data tag for the model number of the product furnished. The details of
a specific number are as follows:
53 SL 5 1 _ _ A 2 1 A _ _
Engineering File Reference:
Controllers, Regulators,
and Accessories
53
Single Loop Controller SL
Design Designation: Fixed Data 5
Number of Control Loops:
One Loop
1
Power Requirements
AC (120/240) 1
DC (24) 2
Functional Requirements
Standard 1
Standard with Factory Configuration 2
Design Level A
Enclosure Type
DIN 72 x 144 mm Bezel 2
Main Rear Terminal Requirement
Standard Rear Terminal 1
Chassis
Standard A
Safety Classification
General Purpose A
FM Approved: Non-incendive for Class 1, Div. 2, Groups A,B,C, & D B
Conforming Coating
Not Required X
Required A
