Single Loop Process Controller Instruction Manual
Front Panel 27
F3 (EMODE
E NTER key) In the configuration function,
pressing this pushbutton
causes the addressed
datapoint to be altered with the
character string that was
entered with the EMODE
Cursor Control and Character
Select pushbuttons. In display
function, pressing this
pushbutton causes the
addressed datapoint to display
its contents.
● Mode Select/Alarm
Reset This pushbutton clears the flashing ALARM message, but the
alarm indication remains until the process variable is restored
within tolerable limits past dead band. It is also used to toggle
between Operator and Engineering modes. If no ALARM
message is present, pressing this pushbutton will toggle the
instrument between Operator mode and Engineering mode.
Table 3-1. Pushbutton Functions (Continued)
Push-
button
Title Operator Mode Engineering Mode
