Single Loop Process Controller Instruction Manual
52 Configuration Parameters
Point 3
Designator PDC F089 C108
value A database datapoint whose contents will be
displayed under the Point 3 Name (e.g., C105 to
display the Alarm Dead Band).
Modify Disable PMD L313 0 When this value is 1, the datapoints in this
module can not be altered with the pushbuttons.
The values of these datapoints are only for
display purposes. When this value is 0, the
datapoints in this module can be altered by the
operator with the pushbuttons when this module
is displayed.
Table 4-10. Communication Module
Title Symbol
CCO0
Datapoint
Default Attribute
Purpose: This module is used to configure the Datalink port parameters (e.g., baud rate, parity selection,
etc.).
Instrument
Address IA B01 0 This item identifies the address of this instrument on
the Datalink network. Each unit connected to the
Datalink network must have its own unique address.
Valid addresses are from 0 to 31.
Baud Rate
BR B02 253
This datapoint value designates the baud rate (data
transfer rate) of the Datalink network. The baud rate
must be the same for all of the instruments
connected to the same Datalink network. Datapoint
values and their corresponding baud rates are as
follows:
Value Baud Rate Value Baud Rate
255
254
N/A
253
250
244
232
208
160
N/A 28800
14400
N/A
9600
4800
2400
1200
600
300
N/A
9
8
7
6
5
4
3
2
1
0 28800
14400
19200
9600
4800
2400
1200
600
300
110
No Parity CP L2561 0 This datapoint indicates if parity generation and
checking should be turned on or off. It is set to 0 for
even parity serial byte protocol. It is set to 1 for no
parity protocol.
Table 4-9. Parameter Display Module (Continued)
Title Symbol PAR1 Default Attribute
