Single Loop Process Controller Instruction Manual
Analog Backup Controller 69
→ Output Increase
(EMODE Cursor
Control) The output indicator increases when
this pushbutton is pressed and held.
Release the pushbutton when the
desired output level is reached. This
pushbutton is for Manual operation
only when the controller is in Local. For configure or display functions,
the cursor shifts one position to the
right each time this pus button is
pressed. When pressed and held,
characters continue to shift right
one position at a time. Maximum
character length is 10 characters (9
character shifts).
F1, F2 Page Forward
and
Page Back These two pushbuttons have similar
functions, but work in reverse of one
another. They are the bar graph -
parameter display toggles. The two
display types interchange and
alternately appear each time either
one of these two pushbuttons is
pressed. Push button
F2 is used to select the
configure or display functions in
EMODE. Pressing
F2 in EMODE
alternately selects one function or
the other.
F3 (EMODE E NTER
Key)
In the configuration function,
pressing this pushbutton causes the
addressed datapoint to be altered
with the character string that was
entered with the EMODE Cursor
Control and Character Select push
buttons. In display function,
pressing this pushbuttono causes
the addressed datapoint to display
its contents.
● Mode Select/Alarm
Reset This pushbutton clears the flashing ALARM message, but the alarm
indication remains until the process variable is restored within tolerable
limits past dead band. It is also used to toggle between Operator and
Engineering modes. If no ALARM message is present, pressing this
pushbutton will toggle the instrument between operator and engineering
mode.
Table 6-1. Analog Backup Controller Pushbutton Functions
Button Title Operator Mode Engineering Mode
