Single Loop Process Controller Instruction Manual
50 Configuration Parameters
Reverse Valve RSV
■ ● ▲
u L109 0 This parameter provides information for the
control display to indicate which direction the
control output must go to close the final
control element. A 1 indicates that 20 mA
closes the valve. A 0 indicates that 20 mA
opens the valve.
Manual
Fallback
Disable MFD
■ ● ▲ ◆
L120 0 Under normal operation, whenever the
controller is powered up, the Auto/Manual
Selector is forced to the Manual position.
When this datapoint is set to a 1, the selector
will not be forced to the Manual position at
power up but will remain in the last position
before power was removed.
Alarm Limit 1 PL1
■ ● ▲ ◆
C103 100 These parameters are the points in
engineering units at which the alarms are
triggered.
Alarm Limit 2 PL2
■ ● ▲ ◆
C104 0
Alarm Dead
Band ADB
■ ● ▲ ◆
C105 2 This parameter sets the activation/
deactivation gap for the alarm. This value in
engineering units defines an area of
hysteresis at the alarm point.
Proportional
Band
PB
■ ● ▲ ◆
C106 100
This parameter is the percent of error
required to move the output full scale for
proportional action. It modifies the controller
response in standard PID terms.
Reset Time TR
■ ● ▲ ◆
C107 0 This parameter represents the number of
minutes per repeat of integral action. It
modifies the controller response in standard
PID terms.
Rate Time TD
■ ● ▲ ◆
C108 0 This parameter value represents the minutes
that proportional action is advanced
(derivative action).
Manual Reset MR
■ ● ▲ ◆
u
C111 50 This parameter determines the position of the
valve (output) when the instrument is in
Automatic mode and the error is zero. (It is
only in effect when TR = 0.)
Table 4-8. Controller Module (CON-0) (Continued)
Title Symbol
CS
■ ● ▲ ◆
1 | 2 | 3 | 4
CON-0
Datapoint
Default Attribute
