Front Panel 33
3.3.4 Responding to the Prompt KEY?
When the password prompt KEY? appears, it indicates a password was set with an external device (e.g.,
Hand-Held Configurer, PC, etc.). The password can not be set via the front panel keys. A password key is
a maximum of 10 numeric characters (numbers 0-9 only). It does not impede display functions in EMODE
but must be unlocked to perform configuration functions.
✎ Notes A password key is NOT SET FOR NEW INSTRUMENTS from the
factory; therefore, if it is set, it had to have been done locally. The
password must first be obtained from the originator before the
procedure in
Table 3-5 can be used to access the EMODE
configuration function capabilities.
Table 3-5. Entering a Key Password
Step Press
Shift
Result
Press to
Locate
Target
Char.
Result
1 MODE Puts instrument in EMODE.
2 If CONFIGURE does not appear, press F2.
3 F3 Displays password query: KEY? .
4 ↑
N Puts first password number on entry line:
KEY? .N.
5 ← .N ∆ ↑ N Shifts N and puts second password number on
entry line: KEY? .NN.
6 ← .NN ∆ ↑ N Shifts NN and puts third password number on entry
line: KEY? .NNN.
7 Repeat Step 6 until all of the password characters are entered.
8 F3 It enters the password key and displays the entry
line: POINT . the EMODE configuration function is
now accessible for use.
Note: ∆ = space, N = any numeric value 0-9.
