Single Loop Process Controller Instruction Manual
Front Panel 37
3.4.1.2 Displaying a Database Parameter
To display a database parameter, press D and enter the parameter ID, then press
E NTER . The current value
of the parameter is displayed. The parameter ID is the data type identifier (B, L, C, H, F, and A) and point
number as described in
Figure 4-1 in Section 4 . For example, to display the value of datapoint B12, press:
D B12
The value presently assigned to B12 is displayed.
Values displayed with the D command are formatted as follows:
Pressing E NTER after pressing D automatically recalls the last data base parameter ID used.
Pressing N after pressing D causes the next parameter of the same data type to be displayed. (The NEXT
command N only works with index numbers below 256.)
3.4.1.3 Altering a Database Parameter
To modify a value or enter a new value press P and the parameter ID followed by
E NTER . Then press the
keys corresponding to the value to be assigned, followed by E NTER . For example, to set B00 to 97 to initiate
the display test, press:
P B0 097
Values entered with the PUT command P must be formatted as follows:
In general, all modification inputs are limited to the first ten characters of the field.
For B data type parameters, the value entered must be between 0 and 255.
For L data type parameters, the value must be 1 or 0.
All responses are completed by pressing
E NTER .
Pressing
E NTER after pressing P automatically recalls the last database parameter.
Pressing N after pressing P causes the next parameter of the same data type to be displayed. (The NEXT
command N only works with index numbers below 256.)
3.4.1.4 Setting or Changing a Password Key
As a security feature, the instrument can be configured so that a password key is required to access the
Engineering Mode configuration function. The password key can only be set by the Hand-Held Configurer,
or the 53HC3300 or 53WS5000 software packages via a PC, or SUPERVISOR-PC, and not by the instru-
ment front panel keys.
A password key is a special data type (Q1) that is displayed or configured just like any other data type
using the Hand-Held Configurer. The value assigned to a password key must be an ASCII numeric string
Data Type Data Format
B Are three digit characters 000-255.
L Is a one digit character 0 or 1.
C & H Are ten digit characters including digits,
decimal point and sign (when negative).
Zero = 0.0
F Are five characters or less.
A & Q Are ten characters or less.
