Single Loop Process Controller Instruction Manual
Database 141
Datalink
No Byte
Stuffing CB L258 0 When set to a 1, this datapoint disables the standard
MicroMod communication protocol feature which inserts
a 00 (NUL) byte after every 7EH (SOH) that is not the
beginning of a message. (This permits user-written
communications software to determine the number of
bytes to expect in a response message.) It must be set to
0 when using MicroMod communications software or
equipment.
CCI
Input
Invert IINV L264 0 This bit reverses the action of CCI datapoint L000
(Contact Input); therefore, the action of this bit is
explained in datapoint L000.
CCO
Output
Invert OINV l288 0 This bit reverses the action of CCO datapoint L024
(Contact Output); therefore, the action of this bit is
explained in datapoint L024.
Parameter
Display
Modify
Disable PMD L313 0 When this value is 1, the datapoints in this module can
not be altered with the pushbuttons. The values of these
datapoints are only for display purposes. When this value
is 0, the datapoints in this module can be altered by the
operator with the pushbuttons when this module is
displayed.
ANI0
0 - 5 V
Input NOBIAS L416 0 Setting this parameter to 1 indicates the input range is
from 0 - 5 volts (0-20 mA) for ANI0. A 0 indicates the
input range is from 1 - 5 volts (4-20 mA) for ANI0.
ANI1
0 - 5 V
Input NOBIAS L417 0 Setting this parameter to 1 indicates the input range is
from 0 - 5 volts (0-20 mA) for ANI1. A 0 indicates the
input range is from 1 - 5 volts (4-20 mA) for ANI1.
ANI0
Square
Root Signal SQRT L440 0 When a 0, it indicates the analog input 0 signal should be
interpreted linearly.
When 1, it indicates the analog input signal should be
interpreted as a square root representation of the value.
When square root is selected, input signals less than 1%
(10% input range) force the input to its zero value.
ANI1
Square
Root Signal SQRT L441 0 When a 0, it indicates the analog input 1 signal should be
interpreted linearly.
When 1, it indicates the analog input signal should be
interpreted as a square root representation of the value.
When square root is selected, input signals less than 1%
(10% input range) force the input to its zero value.
ANO0
0 - 20 mA
Output
OZBASE L472 0
When a 0, the percentage output of ANO0 generates a
4-20 mA signal. When set to 1, the percentage output of
ANO0 generates a 0 - 20 mA signal.
Table C-2. Database (Continued)
Title Symbol Datapoint Default Attribute
