Table 8-7. communication module, Table 8-8. system module, Table 8-8 – Micromod Micro-DCI: 53SL5100A Single Loop Controller User Manual
Page 101
Single Loop Process Controller Instruction Manual
Automatic/Manual Station 93
Table 8-7. Communication Module
Title
Symbol
Datapoint
Default
Instrument
Address
IA
B01
0
Baud Rate
BR
B02
253
No Parity
CP
L256
0
No Byte
Stuffing
CB
L258
0
Datalink
Disable
DLD
L257
0
Table 8-8. System Module
Title
Symbol
System Module
Datapoint
Default
Function Index
FIX
B00
0
Display Brightness
Index
BRIGHT
B12
4
Unit Tag Name
TAG
A08
SL5100
