Single Loop Process Controller Instruction Manual
Database 135
Function
Index
FIX
B000
0
The operational algorithm of the unit is selected by the
value of this parameter:
0 = Suspend Mode; no control algorithm execution.
The logo is displayed.
1 = CS1, Single Loop PID Controller operation.
2 = CS2, Analog Backup Controller operation.
3 = CS3, Ration Controller operation.
4 = CS4, Automatic/Manual Station operation.
97 = Display Test. The entire display alternately
flashes on and off. When off, a border around
the display perimeter remains lit.
98 = Default Database. Defaults the database,
then sets FIX 0 for suspend mode, which
displays the logo.
Datalink
Instrument
Address
IA
B001
0
It identifies the address of this instrument on the Datalink
network. Each unit connected to the Datalink network
must have its own unique address. Valid addresses are
from 0 to 31.
Datalink
Baud Rate
BR
B002
253
This datapoint value designates the baud rate (data
transfer rate) of the Datalink network. The baud rate must
be the same for all of the instruments connected to the
same Datalink network. Datapoint values and their
corresponding baud rates are as follows:
Value Baud Rate Value Baud Rate
255
254
N/A
253
250
244
232
208
160
N/A
28800
14400
N/A
9600
4800
2400
1200
600
300
N/A
9
8
7
6
5
4
3
2
1
0
28800
14400
19200
9600
4800
2400
1200
600
300
110
EASY-
TUNE
Enable
ETE
B008
0
When set to a 1, the EASY-TUNE algorithm is
implemented. This parameter is left at 0 for normal
instrument operation. (See
.)
Display
Brightness
Index
BRIGHT
B012
4
This parameter controls the display screen intensity.
A value of 0 is the brightest, and a value of 7 is the
dimmest intensity. Normal viewing setting is 4.
ANI0
Calibrate
Zero
CIZ
B263
This is the calibration zero adjustment. This parameter is
factory set and should not need adjustment under
normal operation. See
for adjustment.
Table C-2. Database (Continued)
Title
Symbol Datapoint
Default
Attribute
