Single Loop Process Controller Instruction Manual
58 Single Loop (PID) Controller
This push button is the Auto/Manual mode toggle. When toggled to Auto, an A appears before the R or L
Table 5-1. Single Loop Controller Pushbutton Functions
Button Title Operator Mode Engineering Mode
R/L Remote/Local
Select This push button is used to select
between Remote setpoint control
and Local setpoint control.
When in Remote, an R appears in
the lower right of the display. When
in Local, an L appears in the lower
right of the display.
↑ Setpoint Increase
(EMODE Character
Select) The setpoint indicator increases
(rises) when this pushbutton is
pressed and held. Release the
pushbutton when the desired
setpoint level is reached. This
pushbutton is for Local setpoint
control only. For configure or display functions,
the character set displays one
character at a time in ascending
alphanumeric order when this
pushbutton is pressed and held.
Release the pushbutton when the
desired character, number, or
symbol appears.
↓ Setpoint Decrease
(EMODE Character
Select) The setpoint indicator decreases
(falls) when this pushbutton is
pressed and held. Release the
pushbutton when the desired
setpoint level is reached. This push
button is for Local setpoint control
only. For configure or display functions,
the character set displays one
character at a time in descending
alphanumeric order when this
pushbutton is pressed and held.
Release the pushbutton when the
desired character, number, or
symbol appears.
A/M Auto/Manual Select This pushbutton is the Auto/Manual
mode toggle. When toggled to Auto,
an A appears before the R or L (for
Remote or Local), in the lower right
of the display.
When toggled to Manual, an M
appears before the R or L (for
Remote or Local), in the lower right
of the display.
Auto indicates the process is under
instrument control.
Manual dindicates the process is
controlled by the instrument panel
puxhbuttons (e.g., output increase
and decrease).
