3. Fixed Rate: Select “Fixed Rate” drop-down menu to disable fixed
speed rate or select a fixed speed rate for Ethernet Extender port from
the “Fixed Rate” drop-down list.
Fixed Rate: bps
Disable
59M /
31M
52M /
24M
47M /
14M
42M / 8M
35M / 6M
28M / 5M
25M / 2M
22M / 1M
14M / 1M
1M / 1M
4. Update Setting: Select “Update Setting” button to finish Fixed Rate
setting.
• Disable Asymmetric Mode:
1. Asymmetric Mode: Check “Disable” to disable asymmetric mode for
Ethernet Extender port.
2. Update Setting: Select “Update Setting” button to finish disabling
asymmetric mode for Ethernet Extender port.
3. Max. Speed: Select “Max. Speed” drop-down menu to select a
maximum speed for Ethernet Extender port from the “Max. Speed”
drop-down list.
Max. Speed: bps
50M
40M
30M
25M
20M
15M
10M
5M
3M
1M
