VLANID The VID of the VLAN that will be enabled or disabled on the
bridge <2-4094>.
GROUP <1-1> The ID of the bridge-group on which the VLAN will be
affected.
VLAN_NAME The ASCII name of the VLAN. Maximum length: 16
characters.
enable Sets VLAN into an enable state.
disable Sets VLAN into a disable state.
4. Example:
The following example enables the vlan VLANID (2) and name
VLAN_NAME (vlan2) of bridge GROUP (1):
switch_a(config-vlan)#vlan 2 bridge 1 name vlan2 state enable
switch_a(config-vlan)#
802.1Q Port Setting
Switchport mode access:
1. Command Mode: Interface mode
Logon to Configure Mode (Configure Terminal Mode).
Then logon to Interface mode.
fe1 means port 1.
The switch_a(config-if)# prompt will show on the screen.
switch_a(config)#interface fe1
switch_a(config-if)#
2. Usage:
Use switchport mode access command to set the switching characteristics
of the Layer-2 interface to access mode, and classify untagged frames only.
Use the no switchport access command to reset the mode of the Layer-2
interface to access (default).
3. Command Syntax:
switchport mode access
no switchport access
4. Example:
The following example sets the switchport mode access of the interface
fe1 (port 1):
switch_a(config)#interface fe1
switch_a(config-if)#switchport mode access
switch_a(config-if)#
