The following example specifies the bandwidth ratios of the transmit
queues on the Ethernet Extender Switch:
switch_a(config)#wrr-queue bandwidth 1 2 4 8
switch_a(config)#
802.1p Priority
1. Command Mode: Configure mode
Logon to Configure Mode (Configure Terminal Mode).
The switch_a(config)# prompt will show on the screen.
switch_a(config)#
2. Usage:
Use wrr-queue cos-map command to specify CoS values for a queue.
3. Command Syntax:
wrr-queue cos-map QUEUE_ID COS_VALUE
QUEUE_ID Queue ID. Range is 0-3.
COS_VALUE CoS values. Up to 8 values (separated by spaces). Range is
0-7.
4. Example:
The following example shows mapping CoS values 0 and 1 to queue 1 on
the Ethernet Extender Switch:
switch_a(config)#wrr-queue cos-map 1 0 1
switch_a(config)#
DSCP
1. Command Mode: Configure mode
Logon to Configure Mode (Configure Terminal Mode).
The switch_a(config)# prompt will show on the screen.
switch_a(config)#
2. Usage:
Use mls qos map dscp-queue command to map the DSCP values to a
queue.
3. Command Syntax:
mls qos map dscp-queue DSCP_VALUE to QUEUE_ID
DSCP_VALUE DSCP values. Up to 8 values (separated by spaces). Range
is 0-63.
QUEUE_ID Queue ID. Range is 0-3.
